140ATI03000C 莫迪康Modicon控制模块

140ATI03000C 莫迪康Modicon控制模块

精度随温度变化
0.15µV/°C + 0.0015%的读数/°Czui大低电平电压
共模抑制
> - 120 dB 50/60 Hz
通道和总线之间的隔离
1780v AC 60s
2500v直流60s
通道间隔离
300v直流
220v交流电
更新时间
1000毫秒
故障类型
断丝
Overtacking规模
标记
CE
冷端补偿
内部32…140°F(0…60°C)
当地的信号
对于总线通信存在(Active) 1个LED(绿色)
用于外部故障1 LED(红色)
为通道打开8个led(绿色)
通道故障8个led(红色)
母线电流要求
280毫安
功耗(W)
1.5 W
模块的格式
标准
净重
0.66 lb(US) (0.3 kg)

140ATI03000C 莫迪康Modicon控制模块

Accuracy drift according to temperature
0.15 µV/°C + 0.0015 % of reading/°C max low level voltage
Common mode rejection
> - 120 dB 50/60 Hz
Isolation between channels and bus
1780 V AC 60 s
2500 V DC 60 s
Isolation between channels
300 V DC
220 V AC
Update time
1000 ms
Fault type
Broken wire
Overtacking scale
Marking
CE
Cold junction compensation
Internal 32…140 °F (0…60 °C)
Local signalling
For bus communication is present (Active) 1 LED (green)
for external fault 1 LED (red)
for channel is turned on 8 LEDs (green)
for channel fault 8 LEDs (red)
Bus current requirement
280 mA
Power dissipation in W
1.5 W
module format
Standard
Net Weight
0.66 lb(US) (0.3 kg)

140ATI03000C 莫迪康Modicon控制模块
