Allen-Bradley 1762-IQ16 是一款 16 点灌电流和拉电流输入模块。它的尺寸为 90 x 87 x 40 毫米，在 24 伏直流输入电源下运行，工作电压为 10 至 30 伏。其zui大散热为 3.7 瓦。1762-IQ16 增强了 MicroLogix 1100、1200 和 1400 控制器的功能。它需要zui小的空间，可以安装在DIN导轨或面板安装上。1762-IQ16 模块是一个灌电流和拉电流模块，用于调节输入模块和连接设备之间的电流。模块负极的器件是灌电流场器件，正极的器件是源极磁场器件。源设备始终向接收器设备提供电流。1762-IQ16 模块具有一个状态 LED，用于指示电源并帮助识别所有问题的根源。该模块通过 1762 总线接口通信并接收 10、24 和 30 伏直流电源。用于连接输入接线端子，包括一个手指安全盖。1762-IQ16 使用字 0 的位位置 0 到 15 作为输入端子。安装后必须为每个通道配置模块的操作细节。

故障排除时，请始终与设备保持安全距离，并始终检查程序中是否有任何更改。安全电路应始终串联到主继电器。1762-IQ16 模块应安装在无害、干燥和清洁的环境中，其电路不超过过压 II 类标准。为避免损坏 1762-IQ16，请在执行任何维护任务之前采取预防措施以避免静电放电并断开所有电源。1762-IQ16 是一款 Allen-Bradley MicroLogix 直流输入模块。1762-IQ16 是一款 16 点灌/拉输入模块，输入电压额定值为 24 V DC。该模块具有DIN导轨和面板安装选项。

Allen-Bradley 1762-IQ16 是一款十六 （16） 通道分立输入模块，可与 MicroLogix 1100、1200 和 1400 可编程逻辑控制器配合使用。该 PLC 具有紧凑的外形，其中集成了作为 PLC 运行的zui低硬件要求，例如电源、输入和输出、通信端口和存储器。

根据所使用的 MicroLogix 控制器，扩展模块支持各不相同。如果 1762-Q16 与 MicroLogix 1100 一起使用，则zui多可以使用四 （4） 个扩展模块。如果与 MicroLogix 1200 一起使用，zui多可使用六 （6） 个模块。对于 MicroLogix 1400，zui多可使用七 （7） 个 17620IQ16。扩展模块并非仅适用于 1762-IQ16。扩展模块可以是 MicroLogix 系列中任何模块的组合。

1762-IQ16 具有十六 （16） 个支持下沉和拉电流的通道。每个通道可以连接到承载标称电压为 24VDC 的现场输入设备。每个通道在ON至OFF和OFF至ON转换时均具有8.0 ms的信号延迟。这些输入通道非常适合连接现场设备，例如限位开关、继电器和磁接触器触点、接近传感器和其他分立器件。

该数据文件包含输入信息，可以用二进制、八进制、十进制和十六进制值表示。这些表示称为基数。

要将此模块连接到 MicroLogix 基本控制器，只需将提供的带状电缆互连到相邻模块中指定的插槽即可。带状电缆建立总线连接并提供配电。
