1783-BMS06TA 是一款 6 端口管理型以太网交换机

1783-BMS06TA 是一款 6 端口管理型以太网交换机

1783-BMS06TA 交换机是具有 6 个端口的 Allen-Bradley 5700 系列管理型以太网交换机。所有 6 个交换机端口都是铜质端口，它们支持快速以太网。支持光纤 SFP 的端口在 1783-BMS06TA 交换机上不可用。全套支持的安全功能包括 MAC ID 端口安全、IEEE 802.1x 安全、CIP 端口控制和故障检测，以及 TACACS+ Radius 身份验证和加密（具有单独的 IOS）。

重复 IP 检测、端口镜像、系统日志和断线检测是支持的诊断功能，SNMP、智能端口、每个端口的 DHCP 和 CLI 功能是 1783-BMS06TA 交换机支持的管理功能。网络地址转换 （NAT） 可作为单独的选项使用。1783-BMS06TA 开关上的报警继电器额定电流为 1 安培（30 伏直流电）或 0.5 安培（48 伏直流电）。

该开关在 12 至 48 V DC 的直流输入下工作，消耗的电流范围为 0.5 至 2 安培。功耗为 15 瓦。1783-BMS06TA 开关的重量约为 2.45 磅。开放式交换机外壳尺寸为 5.1 x 2.94 x 4.59 英寸。为防止过热，Allen-Bradley 建议应保持以下zui小间隙：开关前方 2 英寸，开关两侧 2 英寸，开关顶部和底部周围 2 英寸。

1783-BMS06TA 是一款 6 端口管理型以太网交换机

The 1783-BMS06TA switch is an Allen-Bradley 5700 series managed Ethernet switch with six ports. All 6 switch ports are copper ports and they support fast Ethernet. Ports that support optical SFP are not available on the 1783-BMS06TA switch. The full suite of supported security features includes MAC ID port security, IEEE 802.1x security, CIP port control and fault detection, and TACACS+ Radius authentication and encryption (with a separate IOS).

Duplicate IP detection, port mirroring, system logging, and disconnection detection are supported diagnostic functions, while SNMP, smart port, DHCP per port, and CLI functions are supported management functions of the 1783-BMS06TA switch. Network address translation (NAT) is available as a separate option. The alarm relay on the 1783-BMS06TA switch is rated for 1 amp (30 volts DC) or 0.5 amp (48 volts DC).

The switch operates with a DC input of 12 to 48 V DC and consumes a current range of 0.5 to 2 amps. Power consumption is 15 watts. The 1783-BMS06TA switch weighs about 2.45 pounds. The open switch housing measures 5.1 x 2.94 x 4.59 inches. To prevent overheating, Allen-Bradley recommends maintaining the following minimum gaps: 2 inches in front of the switch, 2 inches on both sides of the switch, and 2 inches around the top and bottom of the switch.
