1783-ETAP1F 是一款用于工业以太网 I/P 通信的以太网 I/P 交换机

1783-ETAP1F 是一款用于工业以太网 I/P 通信的以太网 I/P 交换机

Allen-Bradley ETAP1F 是用于以太网 I/P 网络的工业网络设备。该产品本质上是一个以太网交换机，内置两 （2） 个铜端口和一 （1） 个光纤接口。该模块非常适合连接 Allen-Bradley 设备，例如控制器、通信和可视化设备，以实现工业认可的自动化系统。

1783-ETAP1F 的双铜缆端口支持 10/100 Mbps 和自动协商功能，并支持全双工或半双工模式，而 1783-ETAP1F 的单光纤端口也能够达到 100Mbps，但它支持更长的通信距离，对电噪声和干扰的抗扰度更高。

1783-ETAP1F 是一款外部安装的交换机，不需要背板即可安装，但需要适当的外壳来容纳设备，以保护可能损坏模块的工业元件。1783-ETAP1F 的电源要求为 24VDC（标称），适用范围为 20.4...27.6V 直流电该设备可以使用标准DIN导轨进行安装，也可以直接安装到外壳的安装板上。它支持水平和垂直安装方向，水龙头底部的zui小间隙为 7.62 厘米（3 英寸），水龙头其余两侧的zui小间隙为 2.54 厘米（1 英寸）。对于光缆入口，建议至少 5.08 厘米或 2 英寸，以符合光缆所需的弯曲半径。

1783-ETAP1F 具有内置诊断 LED，例如 OK 和 Link1 以及 Link 2 状态指示灯。

该交换机通过嵌入式两 （2） 个铜缆端口和一 （1） 个光纤接口提供以太网连接。

Allen-Bradley/Rockwell Automation 1783-ETAP1F 以太网/IP 交换机的优点之一是它使用户能够将铜缆和光纤网络结合起来。光纤网络非常适合用于覆盖点之间的更长距离，并且不易受到电噪声的影响，从而提供更清晰的信号。

1783-ETAP1F 是一款用于工业以太网 I/P 通信的以太网 I/P 交换机

The Allen-Bradley ETAP1F is an industrial networking device for Ethernet I/P networks. The product is essentially an Ethernet switch with two (2) copper ports and one (1) fiber optic interface built in. The module is ideal for connecting Allen-Bradley devices, such as controllers, communication and visualization devices, to achieve industry-approved automation systems.

The 1783-ETAP1F's dual copper port supports 10/100 Mbps and auto-negotiation and supports full-duplex or half-duplex mode, while the 1783-ETAP1F's single fiber port is also capable of up to 100Mbps, but it supports longer communication distances and is more resistant to electrical noise and interference.

The 1783-ETAP1F is an externally mounted switch that can be installed without a backplane, but requires a proper housing to house the device to protect industrial components that could damage the module. The 1783-ETAP1F has a power supply requirement of 24VDC (nominal) and an application range of 20.4... 27.6V DC The device can be mounted using standard DIN rails or directly onto the mounting plate of the housing. It supports both horizontal and vertical mounting directions, with a minimum clearance of 7.62 cm (3 in) at the bottom of the tap and 2.54 cm (1 in) at the remaining sides of the tap. For cable intakes, a minimum of 5.08 cm or 2 inches is recommended to conform to the required bending radius of the cable.

The 1783-ETAP1F has built-in diagnostic leds such as OK and Link1 and Link 2 status indicators.

The switch provides Ethernet connectivity through two (2) embedded copper cable ports and one (1) optical fiber interface.

One of the advantages of the Allen-Bradley/Rockwell Automation 1783-ETAP1F Ethernet /IP switch is that it enables users to combine copper and fiber networks. Fiber optic networks are ideal for covering longer distances between points and are less susceptible to electrical noise, providing a clearer signal.
