1783-US16T Stratix 2000 系列非网管交换机

1783-US16T Stratix 2000 系列非网管交换机

Allen-Bradley 的 1783-US16T Stratix 2000 以太网非网管交换机是一种电子设备，可为大多数需要可靠网络连接的工业应用提供紧凑的解决方案。它需要双 2 类或 SELV 16 至 60 伏直流电或 18 至 30 伏交流电，输入电压范围为 50 至 60 赫兹，标称输入为 24 伏，zui大输入电流为 555.5 mA，启动时浪涌电流为 4.72 A。

1783-US16T 在运行时可散发 6.72 的zui大热量，并在电源到网络通道之间提供 30 伏直流电压隔离，使用基本绝缘，在 500 伏交流电下测试 60 秒。它使用 IEC 级 RJ-45 连接器，带有 16 个用于以太网连接的快速以太网端口 （FE），并使用 14 AWG 铜线和 1.82 N-m（8 英寸/磅）螺丝扭矩进行接地连接。1783-US16T zui多支持 8K MAC 地址，但不支持 SFP 模块。

它采用开放式外壳，指定用于 T4 北美和 IEC 温度代码。1783-US16T 具有 -40 至 70 摄氏度（-40 至 158 华氏度）的宽工作温度范围，相对湿度为 5% 至 95%，可适应各种应用。它储存在 -40 至 85 摄氏度（-40 至 185 华氏度）的 IEC 额定温度范围内。它设计用于在非工作模式下承受 15G 和 30G 的运行冲击，并且可以承受 2 至 10 赫兹的 150G 运行振动。它具有CISPR11的 A 级辐射，并具有 IP20 环境等级，可防止固体物体。1783-US16T 的尺寸为 88 x 135 x 146.30 毫米（3.46 x 5.31 x 5.76 英寸），并通过了 C-UL-US、CE、KC、RCM 和 Ex 认证。

1783-US16T Stratix 2000 系列非网管交换机

Allen-Bradley's 1783-US16T Stratix 2000 Ethernet unmanaged switch is an electronic device that provides a compact solution for most industrial applications that require reliable network connectivity. It requires dual Class 2 or SELV 16 to 60 volts DC or 18 to 30 volts AC with an input voltage range of 50 to 60 Hz, A nominal input of 24 volts, a maximum input current of 555.5 mA, and a surge current of 4.72 A at start-up.

The 1783-US16T emits a maximum heat of 6.72 when in operation and provides 30 volts DC voltage isolation between the power supply and the network channel, using basic insulation, testing for 60 seconds at 500 volts AC. It uses IEC grade RJ-45 connectors with 16 fast Ethernet ports (FE) for Ethernet connections and ground connections using 14 AWG copper wire and 1.82 N-m (8 "/ lb) screw torque. The 1783-US16T supports up to 8K MAC addresses, but does not support SFP modules.

It comes in an open housing specified for T4 North America and IEC temperature codes. The 1783-US16T has a wide operating temperature range of -40 to 70 degrees Celsius (-40 to 158 degrees Fahrenheit) and relative humidity of 5% to 95%, making it suitable for a variety of applications. It is stored within the IEC temperature rating range of -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit). It is designed to withstand 15G and 30G operating shocks in non-operating mode, and can withstand 150G operating vibrations from 2 to 10 Hz. It has Class A radiation of CISPR11 and has an IP20 environmental rating that protects against solid objects. The 1783-US16T measures 88 x 135 x 146.30 mm (3.46 x 5.31 x 5.76 inches) and is C-UL-US, CE, KC, RCM and Ex certified.
