2080-LC50-24QWB 是一款可扩展的砖模型控制器

2080-LC50-24QWB 是一款可扩展的砖模型控制器

Allen-Bradley的2080-LC50-24QWB Micro850 24点控制器是一款可扩展的砖模型控制器，具有14个嵌入式输入和10个嵌入式输出，zui多3个插件模块，专为低预算单机而设计。它有1424v的吸收/源(高速)输入电路，有10个继电器输出，2类输入电压范围为20.4-26.4V DC，zui大功耗为28W。控制器在输出到Aux之间以及网络输入到输出之间提供250V交流隔离电压，在3250V DC下测试60s，使用增强绝缘类型。它具有C300和R150先导负载额定值，具有7mm(0.28英寸)绝缘条长度，并且它被封闭在ip20等级的外壳中。该控制器具有6个24V吸源标准直流输入(输入8或更高)，导通状态电压范围为10-30V DC，标称输入阻抗为3.74kOhms，从输入组到背板具有50V直流工作电压隔离，在720V DC下测试2s，使用IEC 2级额定增强绝缘类型。2080-LC50-24QWB有8个隔离的交流输入，在50-60Hz时具有12/24V交流ON状态电压，在50-60Hz工作频率下具有4V AC off状态电压。有10个继电器输出，直流zui大输出电压125V，zui大负载电流2A。它的继电器输出也有一个5A每公共的zui大电流，zui大开/关时间为10ms，它的zui大MAKE/BREAK电流为0.22A, MAKE/BREAK实际额定功率为28VA。它具有iec测试的工作温度范围在-4和149℉之间，在5-95%的非冷凝相对湿度，它被存储在-40和185℉之间。可承受25G的工作冲击，10-500Hz的2G振动，并指定T4(北美)温度代码。它重0.423公斤(0.933磅)，发货时净尺寸为90毫米× 158毫米× 80毫米(3.54英寸× 6.22英寸× 3.15英寸)。

Allen-Bradley 2080-LC50-24QWB是Micro 850可编程逻辑控制器(PLC)。该控制器是Allen-Bradley现代PLC产品系列的一部分，理想地用于微型或小型应用。这种PLC特别受原始设备制造商(OEM)的欢迎，因为它具有小型，可扩展的硬件，但先进的功能和高成本效益。

2080-LC50-24QWB是一款紧凑型PLC，配备了一整套组件，如电源，处理器，I/O和通信接口。该PLC的内置电源为24伏直流电源。嵌入式I/O接口包括十四(14)个输入，十(10)个继电器输出和四(4)个100 kHz高速计数器输入。该控制器zui多支持扩展3个模块。

它支持多达10K的程序步骤或指令，并能够处理多达20K字节的数据。该控制器可以使用IEC 61131-3定义的标准语言进行编程，如梯形图(LD)，功能框图(FBD)和结构文本(ST)。该控制器支持用户自定义块的创建，也能够使用运动指令进行运动和位置控制。该控制器支持32位和64位浮点匹配操作，并能够实现比例+积分+导数(PID)控制。该控制器支持直接面板或DIN导轨安装。

2080-LC50-24QWB 是一款可扩展的砖模型控制器

The 2080-LC50-24QWB Micro850 24 Point Controller by Allen-Bradley is an expandable brick modeled controller with 14 embedded inputs and 10 embedded outputs, up to 3 plugin modules, and it is designed specifically for low-budget, stand-alone machines.  It has 14, 24V sink/source (high-speed) input circuits, with 10 relay outputs, and a Class 2 input voltage range of 20.4-26.4V DC, with 28W maximum power consumption.  The controller provides 250V AC isolation voltage between outputs to Aux, and between network inputs to output, tested at 3250V DC for 60s, using the reinforced insulation type.  It has C300, and R150 pilot duty rating, with 7mm (0.28in) insulation strip length, and it is enclosed in an IP20-rated enclosure.  The controller has six 24V sink/source standard DC inputs (input 8 and higher), with an ON-state voltage range of 10-30V DC, at 3.74kOhms nominal input impedance, and it has 50V DC working voltage isolation, from input group to backplane, tested at 720V DC for 2s, using IEC Class 2 rated reinforced insulation type.  The 2080-LC50-24QWB has 8 isolated AC inputs, with 12/24V AC ON state voltage at 50-60Hz, and an OFF-state voltage of 4V AC at 50-60Hz operating frequency.  It has 10 relay outputs with 125V DC maximum output voltage and a maximum load current of 2A.  Its relay outputs also have a 5A maximum current per common with a maximum Turn ON/OFF time of 10ms, and it has a maximum MAKE/BREAK amperage of 0.22A, and a MAKE/BREAK real power rating of 28VA.  It has an IEC-tested operational temperature range between -4 and 149 oF at 5-95% non-condensing relative humidity, and it is stored between -40 and 185 oF.  It can withstand an operational shock of 25G, with a 2G vibration at 10-500Hz, and it is designated with the T4 (North America) temperature code.  It weighs 0.423kg (0.933lb), and it is shipped with net dimensions of 90mm x 158mm x 80mm (3.54in x 6.22in x 3.15in).

The Allen-Bradley 2080-LC50-24QWB is a Micro 850 Programmable Logic Controller (PLC).  This controller is part of the modern PLC product range of Allen-Bradley that is ideally used in micro or small applications.  This PLC is especially popular with Original Equipment Manufacturers (OEM) due to its small, scalable hardware yet advanced features and highly cost-effective.

The 2080-LC50-24QWB is a compact PLC that comes with a complete set of components such as Power Supply, Processor, I/O and communication interfaces.  The built-in power supply to this PLC is a 24 Volt DC power supply.  The embedded I/O interfaces includes fourteen (14) inputs, ten (10) relay outputs and four (4) 100 kHz high-speed counter inputs.  This controller supports expansion of up to 3 modules.

It supports up to 10K program steps or instructions and is capable of handling up to 20K bytes of data.  This controller may be programmed using the IEC 61131-3 defined standard languages such as Ladder Diagram (LD), Function Block Diagram (FBD) and Structure Text (ST).  This controller supports creation of user-defined blocks and also capable of using motion instruction for motion and position control.  32-bit and 64-bit floating point match operation is supported by this controller and able to implement Proportional + Integral + Derivative (PID) control.  This controller supports direct panel or DIN rail mounting.

2080-LC50-24QWB 是一款可扩展的砖模型控制器
