2094-BC04-M03-S是一个Kinetix 6000驱动系统模块。该组件由Allen-Bradley制造，设计用作变频器的集成轴模块。该模块的额定输出功率在20%负载时为53瓦，40%负载时为72瓦，60%负载时为93瓦，80%负载时为116瓦，100%负载时为142瓦。

该模块有一个转换器和逆变器部分。转换器部分的输出额定值为28kW，逆变器为30安培。该模块也称为AM电源模块。它配有用于电机电源(MP)和电机/电阻制动电源(BC)的接线插头连接器。该模块不提供目录号为2090-K6CK-D44M和2090-K6CK-D44S0的连接器套件输入和输出接口、安全和辅助反馈信号以及目录号为2090-K6CK-D15M的电机反馈。

使用该模块时，并不总是需要接地跳线设置。然而，不接地或高阻抗电源配置需要接地跳线设置。要设置接地跳线设置，请从电源轨上卸下集成访问模块(IAM ),打开电源模块并将跳线位置修改到适当的位置。默认情况下，模块设置为接地位置，其中P16和P17短路，而未接地配置的P18和P19端子短路。

安装2094-BC04-M03-S时，首先安装集成安讯士模块，然后安装IPIM、安讯士模块、分流模块和插槽填充模块。IAM必须安装在电源轨的zui左侧。其他模块位于IAM的右侧。

该模块旨在为您的驱动、电机和执行器应用提供Kinetix集成运动解决方案。

2094-BC04-M03-S具有200V或400V级交流输入电源的安全扭矩关闭功能。它包含一个逆变器和一个转换器部分。峰值增强功能可用于400V级(B和C系列)2094-BC04-M03-S IAM模块。2094-BC04-M03-S变频器可以连接到接地跳线。

2094-BC04-M03-S的功耗(以瓦特为单位)因其在给定时间内的功率输出百分比而异。例如，2094-BC04-M03-S在20%额定功率输出时的功耗为94 W，在100%额定功率输出时的功耗为255 W。2094-BC04-M03-S有3个系列(A、B和C)，这些系列有不同的峰值电流额定值。A系列2094-BC04-M03-S变频器的额定峰值电流为150%，而B和C系列2094-BC04-M03-S变频器的额定峰值电流为250%。
