2097-V34PR3-LM 是Kinetix 300以太网I/P伺服驱动器

2097-V34PR3-LM 是Kinetix 300以太网I/P伺服驱动器

Allen-Bradley 2097-V34PR3-LM是Kinetix 300以太网I/P伺服驱动器。该驱动器专门设计用于简化集成到更高和现代控制系统，因为它带有嵌入式以太网通信接口，可用于建立连接到现有或新安装的以太网网络。通过嵌入式以太网端口，该驱动器可以集成到CompactLogix和ControlLogix可编程自动化控制器(PAC)中。

通过将驱动器集成到支持的PAC产品中，驱动器参数成为用户程序的一个组成部分，因为它们被转换为指令。这些参数可以根据条件和预编程参数集的状态进行修改。

2097-V34PR3-LM能够提供320-528VAC rms的交流输入电压要求，三相和48-62 Hz的输入频率，而zui大主交流输入电流为2.7安培，标称和zui大涌流额定为4.5安培(0-pk)。该驱动器的连续输出电流(rms)为2.0 A，连续输出电流(0-pk)为2.8安培，而连续输出电流@ 480VAC为1.0 kW。此外，峰值输出电流(rms)为6.0 A，峰值输出电流(0-pk)为8.5安培。该驱动器具有安全的扭矩关闭功能。此外，2097-V34PR3-LM的过电压额定值为850VDC，短路电流额定值为100,000 A (rms)对称。

2097-V34PR3-LM配备的额定功率为1.0千瓦，可为各种操作提供zui佳功率。该设备还具有连续输出电流，总额定值为2.8安培。设备提供的这种电源选项组合确保了zui佳的功能和高性能，无论安装设置和附加到设备的特定设备如何。为了获得zui佳性能，设备需要480伏AC的额定输入电压，这符合大多数工业电源设置;因此，通常不需要额外的变压器来为该设备提供正确的输入额定电压。希望依赖2097-V34PR3-LM的设施应确保他们获得在工业环境中有经验的专业技术人员进行设备的初始安装。为了获得足够的性能，必须完成各种写入操作;不正确的安装可能导致不稳定或不必要的操作故障，使设施面临进一步复杂化的风险。

2097-V34PR3-LM 是Kinetix 300以太网I/P伺服驱动器

The Allen-Bradley 2097-V34PR3-LM is a Kinetix 300 Ethernet I/P servo drive.  This drive is especially designed to simplify integration to higher and modern control systems as it comes with an embedded Ethernet communication interface which may be used for establishing connection to an existing or newly installed Ethernet network.  With the embedded Ethernet port, this drive may be integrated to CompactLogix and ControlLogix Programmable Automation Controllers (PAC).

By integrating the drive to the supported PAC products, the drive parameters becomes an integral part of the user program as they are converted as instructions.  These parameters may be modified based on the state of the conditions and pre-programmed parameters sets.

The 2097-V34PR3-LM comes is enabled providing an AC input voltage requirement of 320-528VAC rms, 3-phase and input frequency of 48-62 Hz while the maximum main AC input current is 2.7 Amperes, nominal and maximum inrush current rating of 4.5 Amperes (0-pk).  This drive has continuous output current (rms) of 2.0 A, continuous output current (0-pk) of 2.8 Amperes while the continuous output current @ 480VAC is 1.0 kW.  Additionally, the Peak output current (rms) is 6.0 A and the Peak output current (0-pk) is 8.5 Amperes.  This drive features a safe Torque-Off functionality.  Additionally, the 2097-V34PR3-LM has an overvoltage rating of 850VDC and short0circuit current rating of 100,000 A (rms) symmetrical.

The 2097-V34PR3-LM comes equipped with a power rating of 1.0 kWatts, which offer optimal power for a variety of operations.  The device also has a continuous output current with a total rating of 2.8 Amperes.  This combination of power options provided by the device ensures optimal functionality, and a high-performance regardless of the installation settings and particular equipment attached to the device.  An input voltage rating of 480 Volts AC is required by the device for optimal performance, which fits the majority of industrial power settings;  thus there would usually not be any need for an additional transformer to deliver the correct input voltage rating to this device.  Facilities that want to rely on the 2097-V34PR3-LM should ensure that they obtain a professional technician who is experienced in industrial settings for the initial installation of the device.  A variety of writing operations must be completed for adequate performance;  incorrect installation may lead to unstable or unwanted operational glitches, putting the facility at risk of further complications.
