2715P-T12WD-K 操作界面终端是一款触摸屏终端

2715P-T12WD-K 操作界面终端是一款触摸屏终端

2715P-T12WD端子是Allen-Bradley PanelView 5510系列端子。它被设计为可视化和控制工业应用的操作界面终端。Allen-Bradley 2715P-T12WD终端也可用于通过以太网/IP工业网络控制Allen-Bradley ControlLogix L7和L8控制器和Allen-Bradley CompactLogix L1, L2和L3控制器。这个终端带有动画图形。

Allen-Bradley PanelView 5510 2715P-T12WD操作界面终端是一款触摸屏终端。它没有物理键盘，但它需要的所有控制都是终端屏幕上的虚拟按键，用户可以用指尖或触控笔激活这些按键。终端屏幕宽12.1英寸，图形为WXGA TFT彩色图形，清晰美观。触摸屏的宽高比为16:10，分辨率为1280 x 800像素。2715P-T12WD终端采用直流电源供电，内存分为1gb用户内存和1gb RAM。该终端的额定使用温度范围为32至131华氏度(0至55摄氏度)。在持续高温的环境中使用时，应避免阳光直射，并配备冷却风扇或其他冷却设备。

2715P-T12WD-K 操作界面终端是一款触摸屏终端

The 2715P-T12WD terminal is an Allen-Bradley PanelView 5510 series terminal.  It is designed to be an operator interface terminal for visualizing and controlling industrial applications.  The Allen-Bradley 2715P-T12WD terminal can also be utilized to control the Allen-Bradley ControlLogix L7 and L8 controllers and Allen-Bradley CompactLogix L1, L2, and L3 controllers over the EtherNet/IP industrial network.  This terminal comes with animated graphics.

The Allen-Bradley PanelView 5510 2715P-T12WD operator interface terminal is a touchscreen terminal.  It does not come with a physical keypad, but all of the controls that it needs are available as virtual keys on the terminal's screen that the users can activate with their fingertips or with styluses.  The screen on the terminal is 12.1 inches wide and its graphics are WXGA TFT color graphics that are clear and attractive.  The aspect ratio of the touchscreen is a ratio of 16:10 and it has a resolution of 1280 x 800 pixels.  The 2715P-T12WD terminal operates on DC power and its memory is divided between 1 GB of user memory and 1 GB of RAM.  This terminal is rated for use in a temperature range between 32 and 131 degrees Fahrenheit (0 and 55 degrees Celsuis).  It should be kept away from direct sunlight and supplied with cooling fans or other kinds of cooling equipment when it is used in a consistently hot environment.
