Allen-Bradley 5069-OBV8S 是一款紧凑型 5000 I/O 安全输出模块。该模块内置八 （8） 个输出通道，工作电压范围为 17.5-32VDC。该模块适用于要求高达 CL3 和 PLe、Cat 的安全完整性等级 （SIL） 的应用。安全等级。此外，通道安全输入模块。该模块支持寻源接线配置，每通道提供 1 A 的输出电流。

该模块可以与 Compact GuardLogix 5380 控制器一起安装，作为本地 I/O 模块。作为分布式 I/O 模块，该模块可与 GuardLogix 5580 控制器配合使用。

5069-OBV8S 具有检测现场功率损耗、空载、输出短路、过载、输出过热和输出过热检测的功能，而嵌入式保护功能包括反向电压保护和过压保护。

对于安全功能，当控制器进入编程模式或故障模式时，模块的输出通道会自动关闭。当检测到故障时，安全输出切换到 OFF 状态，并将在此状态下重新发送锁定，直到故障原因消除。此外，必须将安全输出调整到安全状态，以使模块恢复正常运行。

5069-OBV8S 符合 SIL CL3、PLe、Cat 的安全完整性等级 （SIL）。4. 安全反应时间（SRT）为4.5ms，zui小输出脉冲宽度为400μs。

这些模块使用生产者和消费者通信系统，该系统由模块和不同设备之间的智能数据传输组成。在这种操作模式下，每个模块都可以生成数据，而无需先轮询。

Allen-Bradley 5069-OBV8S 安全输出模块带有保形涂层，可保护其免受沉闷环境的影响。该模块是直流模块，其 8 点输出的电压为 17.5 至 32 伏直流电。Allen-Bradley 5069-OBV8S 安全输出模块在水平方向上的zui大温度范围为 0 至 60 摄氏度，在垂直方向上的zui大温度范围为 0 至 50 摄氏度。温度不应高于zui高额定值，否则可能会导致过热和模块损坏。模块的输出额定值为每通道 1 安培。电线需要由铜制成，模块的隔离电压额定值高达 250 伏。所有电线都需要紧密且牢固，以避免模块在使用过程中出现故障。
