3500电源模块是半高模块，必须安装在框架zui左边特别设计的插槽内。3500

框架可以安装一个或两个以任意形式组合的交流或直流电源模块:每个电源模
块都能单独为整个框架供电。如果安装了两个电源模块，那么它们一主一备。只要安装了备用电源模块，插拔主电源模块将不会对框架的运行造成中断。

3500电源模块接受宽范围输入电压，并将它们转换成3500模块可接受的工作电压。

3500/15交流与直流电源操作与维护手册

3500交流电源模块有两种型号电源输入模块(PIM)，可接受两种范围的交流

输入电压:高压交流PIM接受175到264Vacrms:低压交流PIM 接受85到

132 Vac rms。

高压直流电源模块支持88到140Vdc直流输入:低压直流电源模块支持20到

30Vdc直流输入。

350053 133388-01 瞬态数据接口模块

The 3500 power module is a half-height module that must be installed in a specially designed slot on the far left side of the frame. 3500

The frame can be mounted with one or two AC or DC power modules in any combination: each power module
Each block can individually power the entire frame. If two power modules are installed, one is active and the other is standby. If a standby power module is installed, the active power module can be removed without interruption.

The 3500 power supply module accepts a wide range of input voltages and converts them into an acceptable operating voltage for the 3500 module.

3500/15 AC and DC Power Supply Operation and Maintenance Manual

3500 AC Power module The AC power input module (PIM) supports two types of AC

Input voltage: High voltage AC PIM accepts 175 to 264Vacrms: Low voltage AC PIM accepts 85 to

132 Vac rms.

The HVDC power module supports 88 to 140Vdc DC input. The low-voltage DC power module supports 20 to 140VDC DC input

30Vdc DC input.
