REL551 1MRK002480-AE通用差动保护端子在电力系统中的作用是至关重要的。它是差动保护装置与电流互感器之间的连接点，起到了桥接和传输电流信号的关键作用。以下是其在电力系统中的主要作用：
电流信号的传输：通用差动保护端子负责将来自电流互感器的电流信号传递给差动保护装置。这些电流信号是差动保护系统进行故障判断的重要依据。
差动保护的触发与隔离：当电力系统中的某一部分发生故障时，差动电流的大小会超过设定值。这时，差动保护装置会根据通用差动保护端子传输的电流信号进行判断，并触发相应的保护动作，如断开故障电路，从而隔离故障，防止其对整个电力系统造成更大的损害。
提高电力系统的可靠性：通过准确、快速地检测并隔离故障，通用差动保护端子帮助提高了电力系统的可靠性。这确保了电力系统的连续供电，降低了因故障导致的停电风险。
提供故障诊断依据：通过分析通用差动保护端子传输的电流信号，还可以为电力系统的故障诊断提供依据。这有助于运维人员快速定位故障点，并进行针对性的维修和恢复工作。

REL551-1MRK002480-AE 差动保护装置


REL551 1MRK002480-AE The role of universal differential protection terminals in power systems is critical. It is the connection point between the differential protection device and the current transformer, and plays a key role in bridging and transmitting the current signal. The following are its main roles in the power system:
Transmission of current signal: The universal differential protection terminal is responsible for transmitting the current signal from the current transformer to the differential protection device. These current signals are the important basis for fault judgment of differential protection system.
Trigger and isolation of differential protection: When a part of the power system fails, the size of the differential current will exceed the set value. At this time, the differential protection device will judge according to the current signal transmitted by the universal differential protection terminal, and trigger the corresponding protection action, such as disconnecting the faulty circuit, so as to isolate the fault and prevent it from causing greater damage to the entire power system.
Improve power system reliability: Universal differential protection terminals help improve power system reliability by accurately and quickly detecting and isolating faults. This ensures a continuous supply of power to the power system, reducing the risk of power outages due to failures.
Provide the basis for fault diagnosis: By analyzing the current signal transmitted by the universal differential protection terminal, it can also provide the basis for the fault diagnosis of the power system. This helps operation and maintenance personnel quickly locate the fault point and carry out targeted repair and recovery work.
