MTL 838B-MBF 模拟多路复用器接收器

MTL 838B-MBF 模拟多路复用器接收器

产品描述

MTL838B-MBF是MTL系列的模拟多路复用器接收器。它的主要作用是接收多个模拟信号，并将这些信号复用成一个信号输出。

特征

•降低安装危险区域布线的成本

•节省安装时间、空间和重量

•快速突出状态报告系统的问题

•使用传感器故障检测和安全驱动器保护过程

•通过串行数据输出直接连接到主机系统

•通过Modbus®通信向控制器进行模拟输入

•冗余数据高速公路

MTL838B-MBF是一种模拟多路复用器接收器，与MTL831B危险区域毫伏输入多路复用器发射器一起使用。多达32个模拟输入的状态可以通过两条数据高速公路从危险区域传输到安全区域，每条数据高速公路由一对简单的双绞线组成，距离可达500米。当输入位于危险区域时，每个数据高速公路必须由MTL3052数字隔离器进行保护。MTL831B通常与热电偶和RTD输入一起使用，本质安全。它可以安装在0区危险区域，可接受16个输入。在单个MTL838B-MBF接收器输入上zui多可组合两个MTL831B变送器，总共32个模拟输入。

MTL 838B-MBF 模拟多路复用器接收器
Product description

The MTL838B-MBF is an analog multiplexer receiver for the MTL family. Its main function is to receive multiple analog signals and multiplexed these signals into a signal output.

trait

• Reduce the cost of installing cabling in hazardous areas

• Save installation time, space and weight

• Quickly highlight issues with status reporting systems

• Process protection with sensor fault detection and secure drives

• Connect directly to the host system via serial data output

• Analog input to the controller via Modbus® communication

• Redundant data superhighway

The MTL838B-MBF is an analog multiplexer receiver used with the MTL831B hazardous area millivolt input multiplexer transmitter. The status of up to 32 analog inputs can be transmitted from the danger zone to the safety zone via two data highways, each consisting of a simple pair of twisted pairs, at distances of up to 500 meters. When the input is located in a hazardous zone, each data highway must be protected by the MTL3052 digital isolator. The MTL831B is typically used with thermocouples and RTD inputs and is inherently safe. It can be installed in zone 0 danger zone and accepts 16 inputs. Up to two MTL831B transmitters can be combined on a single MTL838B-MBF receiver input for a total of 32 analog inputs.
