ANC-100E 以太网/IP到数据高速公路加转换器

ANC-100E 以太网/IP到数据高速公路加转换器

ANC-100e的亮点:
兼容所有PLC编程/HMI/SCADA包，包括所有旧版本的RSLINX Classic和zui新的RSLINX Enterprise。
简单设置:驱动程序选择是ControlLogix以太网驱动程序。
经济型:全功能以太网到DH+转换器，标价1495美元。
Panelview Plus 6 / 7以太网/IP消息传送到DH+上的多个SLC 5/04和PLC-5
快速以太网/IP连接:使用RSLINX Controllogix以太网驱动程序。
AB 1784接口卡兼容性:1784-U2DHP、1784-KTx、1784-PKTx和1784-PCMK卡的现代替代品
DH+速度:可靠地支持所有DH+数据速率–57.6、115.2和230.4波特，通信长度超过标准要求。
自动检测:默认自动波特率和自动极性检测。
尺寸:“口袋大小”的便利性，带桌面和Din导轨选项。
易于DH+连接:3针凤凰蓝软管连接器选项或直接8针迷你din电缆连接到PLC端口。(包括8针迷你din电缆)。

ANC-100E 以太网/IP到数据高速公路加转换器

Highlights of the ANC-100e:
Compatible with all PLC programming /HMI/SCADA packages, including all older versions of RSLINX Classic and the latest RSLINX Enterprise.
Simple setup: Driver selection is ControlLogix Ethernet Driver.
Economy: Full-featured Ethernet to DH+ converter, listed for $1,495.
Panelview Plus 6/7 Ethernet /IP messages are delivered to multiple SLC 5/04 and PLC-5 on DH+
Fast Ethernet /IP connection: Use the RSLINX Controllogix Ethernet driver.
AB 1784 Interface card Compatibility: Modern replacement for 1784-U2DHP, 1784-KTX, 1784-PKTX and 1784-PCMK cards
DH+ Speed: Reliably supports all DH+ data rates - 57.6, 115.2 and 230.4 baud, with communication lengths exceeding standard requirements.
Automatic detection: Default automatic baud rate and automatic polarity detection.
Size: "Pocket size" for convenience, with tabletop and Din rail options.
Easy DH+ connection: 3-pin Phoenix Blue hose connector option or direct 8-pin mini din cable connection to PLC port. (Includes 8-pin mini din cable).
