FC-RUSIO-3224 远程通用安全IO模块

FC-RUSIO-3224 远程通用安全IO模块

产品概述:

倍加福系统板 FC-GPCS-RIO16-PF 是一款专为与霍尼韦尔远程通用安全 I/O 模块 FC-RUSIO-3224 集成的本质安全 I/O 模块而开发的系统板。

产品特点:

本质安全: FC-GPCS-RIO16-PF 模块采用本质安全设计，可用于危险区域。
灵活配置: 模块的 I/O 可以灵活配置，满足不同应用需求。
简单连接: 通过倍加福系统互连线缆 CAHWC300-AIO-DIO-3m 即可与 RUSIO 模块连接。
软件配置: RUSIO 模块的 I/O 配置可以通过软件完成，集成板的 I/O 配置可以通过选择正确的 IS 屏障完成。
定制外壳: 倍加福可提供定制外壳，包括用于安装在危险区域的 1 区解决方案。
应用领域:

FC-GPCS-RIO16-PF 模块可广泛应用于各种工业自动化领域，包括：

过程控制: 在过程控制领域，FC-GPCS-RIO16-PF 模块可用于采集温度、压力、流量等模拟量信号，以及控制阀门、电机等设备。
数据采集: 在数据采集领域，FC-GPCS-RIO16-PF 模块可用于采集各种环境参数。
测试测量: 在测试测量领域，FC-GPCS-RIO16-PF 模块可用于采集各种测试数据。
技术规格:

型号: FC-GPCS-RIO16-PF
通道数: 16
输入类型: 模拟量、数字量
输出类型: 模拟量、数字量
电源: 24V DC
工作温度: -40℃～+70℃
工作湿度: 5%～95%
接线:

FC-GPCS-RIO16-PF 模块的接线方式如下：

输入信号: 使用屏蔽电缆连接输入信号源和模块的输入端子。
输出信号: 使用电缆连接模块的输出端子和外部设备。
电源: 使用电源线连接模块的电源端子和电源。
配置:

RUSIO 模块: RUSIO 模块的 I/O 配置可以通过霍尼韦尔提供的软件完成。
集成板: 集成板的 I/O 配置可以通过选择正确的 IS 屏障完成。
附件:

倍加福系统互连线缆 CAHWC300-AIO-DIO-3m: 用于连接 FC-GPCS-RIO16-PF 模块和 RUSIO 模块。
定制外壳: 倍加福可提供定制外壳，包括用于安装在危险区域的 1 区解决方案。
认证:

FC-GPCS-RIO16-PF 模块已通过霍尼韦尔测试和批准，并获得 ATEX 和 IECEx 认证。

总结:

FC-GPCS-RIO16-PF 模块是一款功能强大、可靠性高、易于使用和配置的本质安全 I/O 模块，可广泛应用于各种工业自动化领域。

FC-RUSIO-3224 远程通用安全IO模块
Product Overview:

The Pepperl + Fuchsia System Board FC-GPCS-RIO16-PF is a system board developed specifically for the intrinsically secure I/O module integrated with the Honeywell remote universal Security I/O module FC-RUSIO-3224.

Product features:

Intrinsically safe: FC-GPCS-RIO16-PF modules are intrinsically safe and can be used in hazardous areas.
Flexible configuration: Module I/O can be flexibly configured to meet different application requirements.
Simple connection: The RUSIO module can be connected via the Pepperl + Fuchs system interconnect cable CAHWC300-AIO-DIO-3m.
Software configuration: The I/O configuration of the RUSIO module can be completed by software, and the I/O configuration of the integrated board can be completed by selecting the correct IS barrier.
Custom enclosures: Pepperl + Fuchs offers custom enclosures, including Zone 1 solutions for installation in hazardous areas.
Application field:

The FC-GPCS-RIO16-PF module can be used in a wide range of industrial automation fields, including:

Process control: In the field of process control, the FC-GPCS-RIO16-PF module can be used to collect analog signals such as temperature, pressure, flow rate, and control valves, motors and other equipment.
Data acquisition: In the field of data acquisition, the FC-GPCS-RIO16-PF module can be used to collect various environmental parameters.
Test and measurement: In the field of test and measurement, the FC-GPCS-RIO16-PF module can be used to collect various test data.
Technical specifications:

Model: FC-GPCS-RIO16-PF
Number of channels: 16
Input type: analog, digital
Output type: analog, digital
Power supply: 24V DC
Operating temperature: -40℃ ~ +70℃
Working humidity: 5% ~ 95%
Connection:

The connection modes of the FC-GPCS-RIO16-PF module are as follows:

Input signal: Use a shielded cable to connect the input signal source to the input terminal of the module.
Output signal: Use a cable to connect the output terminals of the module to external devices.
Power supply: Connect the power terminal of the module to the power supply using a power cable.
Settings:

RUSIO module: I/O configuration of the RUSIO module can be done through software provided by Honeywell.
Integrated board: I/O configuration of the integrated board can be completed by selecting the correct IS barrier.
Attachment:

Pepperl + Fuchland system interconnection cable CAHWC300-AIO-DIO-3m: used to connect the FC-GPCS-RIO16-PF module to the RUSIO module.
Custom enclosures: Pepperl + Fuchs offers custom enclosures, including Zone 1 solutions for installation in hazardous areas.
Certified:

The FC-GPCS-RIO16-PF module has been tested and approved by Honeywell and is ATEX and IECEx certified.

In SUMMARY:

The FC-GPCS-RIO16-PF module is a powerful, reliable, easy-to-use and easy-to-configure intrinsically secure I/O module that can be used in a wide range of industrial automation applications.
