IC200ALG326 13 位模拟输出模块具有 8 个输出通道

IC200ALG326 13 位模拟输出模块具有 8 个输出通道

IC200ALG326 是一款来自 VersaMax I/O 平台的多功能 13 位模拟输出模块。它设计用于生成模拟电压和电流信号，以控制工业自动化应用中的各种执行器、显示器和其他设备。

IC200ALG326模拟输出模块的主要特点：

8 通道输出：该IC200ALG326提供 8 个独立的模拟输出通道，可同时控制多个设备。

高分辨率和高精度：它提供 13 位分辨率，确保精 确和可控的模拟信号生成。

电压和电流输出模式：该模块支持电压和电流输出模式，可满足广泛的应用要求。

输出范围：输出范围可针对各种电压和电流电平进行配置，包括：

电压：-10 V 至 +10 V、0 V 至 +10 V 和 ±5 V DC
电流：4 mA 至 20 mA
内部电源：该IC200ALG326利用内部电源进行操作，无需外部电源。

光隔离：它在输出通道和内部电路之间提供光隔离，防止电噪声和干扰。

诊断 LED：状态 LED（INT PWR LED 和 OK LED）分别指示存在内部电源和正确的背板连接。

低背板电流消耗：该模块在 5 VDC 时的zui大背板电流为 130 mA，从而zui大限度地降低了功耗。

内部断电诊断：它集成了内部断电诊断功能，可检测和报告任何电源问题。

可配置参数：输出范围选择、输出模式选择（电压或电流）和更新速率选择跳线允许自定义模块的输出特性和性能。

高输出阻抗：在电压模式下，zui大输出阻抗为 100 欧姆，而在电流模式下，zui大输出阻抗为 200 欧姆。

低输出噪声：该模块具有低输出噪声，可zui大限度地减少信号失真并确保可靠的信号传输。

IC200ALG326 13 位模拟输出模块具有 8 个输出通道

The IC200ALG326 is a versatile 13-bit analog output module from the VersaMax I/O platform. It is designed to generate analog voltage and current signals to control a variety of actuators, displays and other devices in industrial automation applications.

Main features of IC200ALG326 analog output module:

8-channel output: The IC200ALG326 provides 8 independent analog output channels to control multiple devices simultaneously.

High resolution and precision: It provides 13-bit resolution, ensuring accurate and controlled analog signal generation.

Voltage and current output modes: The module supports voltage and current output modes to meet a wide range of application requirements.

Output range: The output range can be configured for various voltage and current levels, including:

Voltage: -10 V to +10 V, 0 V to +10 V and ±5 V DC
Current: 4 mA to 20 mA
Internal power supply: The IC200ALG326 operates from an internal power supply without the need for an external power supply.

Optical isolation: It provides optical isolation between the output channel and the internal circuit, preventing electrical noise and interference.

Diagnostic leds: Status leds (INT PWR LED and OK LED) indicate the presence of internal power and the correct backplane connection, respectively.

Low backplane current consumption: The module has a maximum backplane current of 130 mA at 5 VDC, which minimizes power consumption.

Internal power outage Diagnostics: It integrates internal power outage diagnostics to detect and report any power problems.

Configurable parameters: Output range selection, output mode selection (voltage or current) and update rate selection jumpers allow you to customize the output characteristics and performance of the module.

High output impedance: In voltage mode, the maximum output impedance is 100 ohms, while in current mode, the maximum output impedance is 200 ohms.

Low output noise: The module has low output noise to minimize signal distortion and ensure reliable signal transmission.
