MPL-B430P-MK74AA 永磁旋转中型惯性电机

MPL-B430P-MK74AA 永磁旋转中型惯性电机

MPL-B430P-MK74AA 是一款高性能、高效率的永磁旋转中型惯性电机。它适用于需要高精度、快速响应和高效率的应用。

特点

高精度：定位精度可达 0.1°
快速响应：转速可达 3000 rpm，加速度可达 2000 rad/s²
高效率：效率可达 85% 以上
中型惯量：转子惯量为 70 g·cm²，可实现平衡的启动和制动性能
运行平稳：噪音低，振动小
使用寿命长：使用寿命长达 20,000 小时
应用

MPL-B430P-MK74AA 可用于各种应用，包括：

机器人
数控机床
包装机械
印刷机械
电子设备
技术规格

参数    值
型号    MPL-B430P-MK74AA
额定功率    430 W
额定转矩    1.0 N·m
额定转速    3000 rpm
峰值转矩    1.5 N·m
峰值电流    10 A
转子惯量    70 g·cm²
电源电压    DC 24 V
额定电流    6 A
工作温度    -20 至 80 °C
防护等级    IP65
尺寸    Ø90 x 130 mm
重量    1.1 kg

MPL-B430P-MK74AA 永磁旋转中型惯性电机

MPL-B430P-MK74AA is a high performance, high efficiency permanent magnet rotating medium inertia motor. It is suitable for applications that require high precision, fast response and high efficiency.

peculiarity

High precision: Positioning accuracy up to 0.1°
Fast response: Speed up to 3000 rpm, acceleration up to 2000 rad/s²
High efficiency: Efficiency can reach more than 85%
Medium inertia: The rotor inertia is 70 g·cm² for balanced starting and braking performance
Smooth operation: low noise, low vibration
Long service life: up to 20,000 hours
Apply

The MPL-B430P-MK74AA can be used in a variety of applications, including:

Robot
Numerical control machine tool
Packaging machinery
Printing machinery
Electronic equipment
Technical specification

Parameter value
Model number MPL-B430P-MK74AA
Rated power 430 W
Rated torque 1.0N ·m
Rated speed 3000 rpm
Peak torque 1.5N ·m
Peak current 10 A
Rotor inertia 70 g·cm²
Power supply voltage DC 24 V
Rated current 6 A
Operating temperature -20 to 80 °C
Protection class IP65
Dimensions Ø90 x 130 mm
Weight 1.1kg
