PPD512-A10-454000 静态励磁系统单元

PPD512-A10-454000 静态励磁系统单元

ABB PPD512-A10-454000静态励磁系统单元是一款高性能励磁系统控制器，专为发电应用中的同步发电机而设计。它是ABB AC800PEC静态励磁系统系列的一部分，以其可靠性、效率和先进的控制能力而闻名。

PPD512-A10-454000静态励磁系统单元的主要特性包括：

高性能控制：PPD512-A10-454000采用先进的控制算法，精 确调节同步发电机的励磁电流，确保稳定的电压和无功功率输出。

模块化设计：该机组采用模块化架构，易于定制和扩展，以满足各种发电机和发电厂配置的特定要求。

全面的保护功能：PPD512-A10-454000 具有全面的保护功能，可保护发电机和励磁系统免受故障和过载的影响。

高 级通信功能：它支持多种通信接口，包括以太网、PROFIBUS DP 和 IEC 61850，有助于集成到监控和数据采集 （SCADA） 系统以及智能电网中。

坚固的结构：该装置由坚固的组件制成，可以承受恶劣的环境，包括极 端温度、振动和电磁干扰。

规格：

输入电压：24 VDC 或 48 VDC

激励电流：高达 40 A

通信接口：以太网、PROFIBUS DP、IEC 61850

工作温度：-20°C 至 +70°C

尺寸：400mm x 300mm x 200mm

应用：

ABB PPD512-A10-454000静态励磁系统单元广泛应用于各种发电应用，包括：

电厂：它是大型电厂励磁控制的常用选择，确保了稳定可靠的发电。

可再生能源系统：该装置用于可再生能源系统，如风电场和太阳能发电厂，以调节同步发电机的励磁。

工业应用：PPD512-A10-454000 用于需要精 确电压和无功功率控制的工业应用，例如大型电机和工业发电机。

微电网：该装置在微电网中得到应用，能够实现分布式能源的协调控制。

总体而言，ABB PPD512-A10-454000静态励磁系统单元是一款功能强大且用途广泛的励磁控制器，可满足广泛的发电需求。

PPD512-A10-454000 静态励磁系统单元

The ABB PPD512-A10-454000 Static excitation System unit is a high performance excitation system controller designed for synchronous generators in power generation applications. It is part of ABB's AC800PEC family of static excitation systems, known for its reliability, efficiency and advanced control capabilities.

The main features of the PPD512-A10-454000 static excitation system unit include:

High performance control: PPD512-A10-454000 adopts advanced control algorithm to precisely adjust the excitation current of synchronous generator to ensure stable voltage and reactive power output.

Modular design: The unit features a modular architecture that is easy to customize and expand to meet the specific requirements of various generator and power plant configurations.

Full protection: The PPD512-A10-454000 has a full range of protection features to protect generators and excitation systems from failure and overload.

Advanced communication capabilities: It supports multiple communication interfaces, including Ethernet, PROFIBUS DP and IEC 61850, facilitating integration into supervisory control and data acquisition (SCADA) systems and smart grids.

Rugged construction: The unit is made of rugged components that can withstand harsh environments, including extreme temperatures, vibration and electromagnetic interference.

Specifications:

Input voltage: 24 VDC or 48 VDC

Excitation current: up to 40 A

Communication interface: Ethernet, PROFIBUS DP, IEC 61850

Operating temperature: -20°C to +70°C

Size: 400mm x 300mm x 200mm

Applications:

ABB PPD512-A10-454000 static excitation system units are used in a wide range of power generation applications, including:

Power plant: It is a common choice for excitation control in large power plants, ensuring stable and reliable power generation.

Renewable energy systems: This device is used in renewable energy systems, such as wind farms and solar power plants, to regulate the excitation of synchronous generators.

Industrial applications: PPD512-A10-454000 is used in industrial applications that require precise voltage and reactive power control, such as large motors and industrial generators.

Microgrid: The device has been applied in the microgrid to achieve coordinated control of distributed energy sources.

Overall, the ABB PPD512-A10-454000 static excitation system unit is a powerful and versatile excitation controller for a wide range of power generation needs.
