PLX31-EIP-ASCII4 四端口通信网关

PLX31-EIP-ASCII4 四端口通信网关

概述

PLX31-EIP-ASCII4 是一款四端口通信网关，可用于在 EtherNet/IP™ 和 ASCII 设备之间进行双向数据传输。该网关由美国 ProSoft Technology 生产，适用于需要在制造业、石油和天然气、电力和食品加工等行业中集成不同类型设备的应用。

主要特点

支持 EtherNet/IP™ 协议和 ASCII 协议
四个独立的端口，每个端口可配置为客户端或服务器
支持显示报文功能
可通过 Web 浏览器进行配置
DIN 导轨安装
应用

PLX31-EIP-ASCII4 网关可用于各种应用，包括：

将 PLC 连接到条形码扫描器或磅秤等 ASCII 设备
将 HMI 连接到 SCADA 系统
将工厂车间设备连接到企业资源计划 (ERP) 系统
技术规格

规格    描述
EtherNet/IP™    支持 PCCC 和 CIP 协议
ASCII    支持 ASCII 和 Modbus RTU 协议
端口    4 个独立的 RS-232/485 端口
波特率    300 至 19200 波特率
数据位    7 或 8 位数据位
奇偶校验    无、奇偶校验、偶校验
停止位    1 或 2 位停止位
电源    24 VDC（10 至 36 VDC 允许）
功耗    典型值 10 瓦
工作温度    -25°C 至 70°C (-13°F 至 158°F)
存储温度    -40°C 至 80°C (-40°F 至 176°F)
尺寸    136.7 x 50.5 x 111.3 mm (5.38 x 1.99 x 4.38 英寸)
重量    340 克 (12 盎司)

PLX31-EIP-ASCII4 四端口通信网关

summarize

PLX31-EIP-ASCII4 is a four-port communication gateway that can be used for bidirectional data transfer between EtherNet/IP™ and ASCII devices. Manufactured by ProSoft Technology, the gateway is suitable for applications that require the integration of different types of equipment in industries such as manufacturing, oil and gas, power and food processing.

Main feature

Supports EtherNet/IP™ protocols and ASCII protocols
Four independent ports, each of which can be configured as a client or server
Supports the display packet function
You can configure this parameter using the Web browser
DIN rail mounting
Apply

The PLX31-EIP-ASCII4 gateway can be used for a variety of applications, including:

Connect a PLC to an ASCII device such as a barcode scanner or scale
Connect the HMI to the SCADA system
Connect plant floor equipment to enterprise resource planning (ERP) systems
Technical specification

Specification description
EtherNet/IP™ supports the PCCC and CIP protocols
ASCII supports the ASCII and Modbus RTU protocols
Ports Four independent RS-232/485 ports
Baud rate 300 to 19200 baud rate
Data bits 7 or 8 data bits
Parity None, parity, parity
Stop bit 1 or 2 stop bits
Power supply 24 VDC (10 to 36 VDC allowed)
Typical power consumption is 10 watts
Operating temperature -25°C to 70°C (-13°F to 158°F)
Storage temperature -40°C to 80°C (-40°F to 176°F)
Dimensions 136.7 x 50.5 x 111.3 mm (5.38 x 1.99 x 4.38 inches)
Weight 340g (12oz)
