G448-0002 桥式输入现场可配置隔离器

G448-0002 桥式输入现场可配置隔离器

G448-0002是一款  由Eurotherm Controls制造的桥式输入现场可配置隔离器。 它是Ultra SlimPak®系列信号调理器的一部分，设计用于隔离和调理工业应用中的电桥或应变片输入。

主要特点：

现场可配置的输入和输出：G448-0002 提供可现场配置的输入和输出范围，可灵活适应各种电桥和应变片应用。

宽输入范围：它支持从 0 开始的宽输入范围。5mV/V至50mV/V以上，适应各种电桥和应变片配置。

精 确零点和量程调整：精 确的零点和量程调整可以微调输入和输出范围，以实现精 确的信号调理。

可选输出范围：输出可设置为 0 至 5V，0 至 10V，0 至 1mA，0 至 20mA，或 4 至 20mA，提供与各种控制系统和记录设备的兼容性。

高隔离度： 隔离器在输入、输出、和力量，保护系统免受接地回路的影响，电噪声，和共模电压误差。

应用：

电桥和应变片信号调理：G448-0002 主要用于调理各种应用中的电桥和应变片信号，例如：

a. 力测量：测量称重传感器、扭矩传感器和压力传感器中的力。

工业过程控制：它在工业过程控制系统中得到了应用，监测和控制参数，例如：

一个。 油箱液位：使用压力传感器测量储罐和料仓中的液位。

b. 力和扭矩监测：监测机械中的力和扭矩，输送 机和机器人系统。

c. 材料应变和应力：监测结构构件的应变和应力，管道和压力容器。

实验室和检测设备：G448-0002 用于实验室和测试设备，用于调节和记录电桥和应变片信号，用于：

一个。 材料性能测试：测量应力-应变曲线和材料性能。

b. 结构载荷测试：监测结构和构件中的载荷和应力。

c. 力和扭矩测量：在实验装置中测量力和扭矩。

好处：

增强的信号质量：G448-0002 隔离器消除了接地环路、电噪声，和共模电压误差，提高信号质量和准确性。

灵活的信号调理：现场可配置的输入和输出范围，宽输入范围，精 确调整可灵活适应各种电桥和应变片应用。

与各种系统的兼容性：可选的输出范围和高隔离度使隔离器与各种控制系统兼容。记录器件，和数据采集系统。

G448-0002 桥式输入现场可配置隔离器

The G448-0002 is a bridge input field configurable isolator manufactured by Eurotherm Controls. It is part of the Ultra SlimPak® series of signal conditioners designed to isolate and condition bridge or strain gauge inputs in industrial applications.

Main features:

Field-configurable inputs and outputs: The G448-0002 offers field-configurable input and output ranges that can be flexibly adapted to a variety of bridge and strain gauge applications.

Wide input range: It supports a wide input range starting from 0. From 5mV/V to 50mV/V and above, suitable for various bridge and strain gauge configurations.

Precise zero and range adjustment: Precise zero and range adjustment fine-tunes the input and output ranges for precise signal conditioning.

Optional output range: The output can be set to 0 to 5V, 0 to 10V, 0 to 1mA, 0 to 20mA, or 4 to 20mA, providing compatibility with various control systems and recording devices.

High isolation: Isolators in input, output, and force protect the system from ground loops, electrical noise, and common-mode voltage errors.

Applications:

Bridge and strain gauge signal conditioning: The G448-0002 is primarily used to condition bridge and strain gauge signals in a variety of applications, such as:

a. Force measurement: Force measurement in load sensors, torque sensors and pressure sensors.

Industrial process control: It is used in industrial process control systems to monitor and control parameters such as:

One. Tank level: Use pressure sensors to measure the level in storage tanks and silos.

b. Force and torque monitoring: Monitoring of forces and torque in machinery, conveyors and robotic systems.

c. Material strain and stress: Monitoring the strain and stress of structural members, pipes and pressure vessels.

Laboratory and testing equipment: G448-0002 is used in laboratory and test equipment to regulate and record bridge and strain gauge signals for:

One. Material properties testing: measurement of stress-strain curves and material properties.

b. Structural load testing: Monitoring of loads and stresses in structures and components.

c. Force and torque measurement: Force and torque are measured in experimental devices.

Benefits:

Enhanced signal quality: The G448-0002 isolator eliminates ground loops, electrical noise, and common-mode voltage errors, improving signal quality and accuracy.

Flexible signal conditioning: Field configurable input and output range, wide input range, precise adjustment for flexible adaptation to a variety of bridge and strain gauge applications.

Compatibility with a variety of systems: The optional output range and high isolation make the isolator compatible with a variety of control systems. Recording devices, and data acquisition systems.
