2098-DSD-HV100-SE 是由 Allen-Bradley （Rockwell Automation） 制造的集成轴模块 （IAM），用于 Ultra 3000 伺服驱动系统。 它是一个功能强大且用途广泛的模块，用作伺服驱动器和单个伺服电机之间的接口，提供精 确的控制和功率分配。
主要特点：
型：编号：2098-DSD-HV100-SE
制造者：Allen-Bradley（罗克韦尔自动化）
Function: Integrated Axis Module (IAM)
轴数：1 轴轴
额定电压：500 伏
额定功率：75 千瓦
连续输出电流：135 安培
峰值输出电流：270 安培
Communication Protocol: EtherNet/IP
应用：高性能伺服控制，机器自动化，包装体系，和机器人技术
好处：
集成设计：将电机控制、配电和通信功能结合在一个紧凑的模块中，简化了系统设计并降低了布线要求。
高性能控制：为要求苛刻的运动应用提供对单个伺服电机的精 确动态控制。
可扩展性：与其他Ultra 3000 IAM兼容，支持多轴伺服系统。
EtherNet/IP 通信：与 EtherNet/IP 网络无缝集成，实现实时通信和控制。
其他注意事项：
系统配置：正确配置 2098-DSD-HV100-SE IAM 以匹配应用的特定电机特性、控制要求和通信参数。
接线和安装：遵循正确的接线和安装规范，以确保模块和连接的电机安全可靠地运行。
编程和配置：利用罗克韦尔自动化编程工具（如 RSLogix 5000）创建必要的运动控制逻辑并配置模块设置。
维护和故障排除：按照制造商的建议进行定期维护检查并遵循故障排除程序，以确保 2098-DSD-HV100-SE IAM 和连接的电机的zui佳性能和使用寿命。

2098-DSD-HV100-SE 一款集成轴模块

The 2098-DSD-HV100-SE is an Integrated shaft module (IAM) manufactured by Allen-Bradley (Rockwell Automation) for the Ultra 3000 servo drive system. It is a powerful and versatile module that acts as an interface between servo drives and individual servo motors, providing precise control and power distribution.
Main features:
Type: Number: 2098-DSD-HV100-SE
Manufacturer: Allen-Bradley (Rockwell Automation)
Function: Integrated Axis Module (IAM)
Number of axes: 1 axis
Rated voltage: 500 volts
Rated power: 75 kW
Continuous output current: 135 amps
Peak output current: 270 amps
Communication Protocol: EtherNet/IP
Applications: High performance servo control, machine automation, packaging systems, and robotics
Benefits:
Integrated design: Combining motor control, power distribution and communication functions in a compact module simplifies system design and reduces cabling requirements.
High-performance control: Provides precise dynamic control of individual servo motors for demanding motion applications.
Scalability: Compatible with other Ultra 3000 IAM, supports multi-axis servos.
EtherNet/IP communication: Seamless integration with EtherNet/IP networks for real-time communication and control.
Other points to note:
System configuration: Correctly configure the 2098-DSD-HV100-SE IAM to match the specific motor characteristics, control requirements, and communication parameters of the application.
Wiring and installation: Correct wiring and installation specifications are followed to ensure safe and reliable operation of modules and connected motors.
Programming and configuration: Create the necessary motion control logic and configure module Settings with Rockwell automation programming tools such as the RSLogix 5000.
Maintenance and troubleshooting: Perform regular maintenance checks and follow troubleshooting procedures as recommended by the manufacturer to ensure optimal performance and service life of 2098-DSD-HV100-SE IAM and connected motors.
