REF615-D 馈线保护和测控装置

REF615-D 馈线保护和测控装置

REF615-D 是一款紧凑型多功能馈线保护和控制继电器，适用于公用事业和工业配电系统。它旨在保护，控制量和监督径向、并监督架空线路和径向电缆馈线，环和网状配电网络，，有或没有分布式发电。REF615-D 是 ABB Relion® 系列的成员，也是其 615 保护和控制产品系列的一部分。
REF615-D 的主要特点
全面的保护功能：REF615-D 提供一整套保护功能，包括：
过流保护：针对过载和故障的定向和非定向过流保护。
接地故障保护：具有多种算法的灵敏和选择性接地故障保护。
距离保护：基于阻抗的线路故障距离保护。
重新关闭：单次和多次重合闸，可在故障后快速恢复服务。
断路器故障保护：检测断路器故障并跳闸。
先进的控制和自动化功能：REF615-D 提供先进的控制和自动化功能，包括：
同步相量测量：支持IEEE C37。118. 1 和 IEC 61850-9-5 用于同步相量测量。
简易爆炸装置通信：支持多种通信协议，包括 IEC 61850，DNP3，和 Modbus。
本地控制和监控：通过大型图形显示屏和按钮进行本地控制和监控。
灵活的配置选项：REF615-D 具有高度可配置性，可满足各种应用的特定需求。它提供了多种标准配置选项，以及使用特定于应用程序的设置进行自定义的能力。
REF615-D的应用
REF615-D 非常适合公用事业和工业配电系统的广泛应用。包括：
架空线路和电缆馈线的保护：REF615-D 可用于保护径向架空线路和电缆馈线，环和网状配电网络。中的架空线路和电缆馈线。
变电站和开关设备的控制：REF615-D 可用于控制变电站和开关设备，包括馈线切换，甩负荷，和孤岛。
电力系统运行状况监控：REF615-D 可用于监控电源系统的运行状况，包括电压，当前和功率因数。
资料收集与分析：REF615-D 可用于收集和分析数据，以便进行系统优化和故障定位。
使用 REF615-D 的优势
REF615-D 为用户提供了多种优势，包括：
提高可靠性：REF615-D 具有全面的保护和控制功能，有助于提高电力系统的可靠性。
提高效率：REF615-D 的高 级自动化功能有助于提高电力系统的效率。
降低维护成本：REF615-D 的自诊断功能有助于降低维护成本。
延长系统寿命：REF615-D 的坚固设计有助于延长电源系统的使用寿命。
总体而言，REF615-D 是一款功能强大、可靠且用途广泛的馈线保护和控制继电器，非常适合公用事业和工业配电系统的广泛应用。

REF615-D 馈线保护和测控装置

The REF615-D is a compact multi-function feeder protection and control relay for utility and industrial distribution systems. It is designed to protect, control volume and supervise radial, and supervise overhead lines and radial cable feeders, ring and mesh distribution networks, with or without distributed generation. The REF615-D is a member of ABB's Relion® family and part of its 615 protection and control product family.
Key features of the REF615-D
Comprehensive protection features: The REF615-D offers a full range of protection features, including:
Overcurrent protection: directional and non-directional overcurrent protection against overloads and faults.
Ground fault protection: Sensitive and selective ground fault protection with multiple algorithms.
Distance protection: Impedance based line fault distance protection.
Re-close: Single and multiple re-close, can quickly restore service after a failure.
Circuit breaker fault protection: Detects circuit breaker failure and tripping.
Advanced control and automation features: The REF615-D offers advanced control and automation features, including:
Synchronous phasor measurement: Support IEEE C37. 1181.1 and IEC 61850-9-5 are used for synchronous phasor measurement.
Ied communication: Supports multiple communication protocols, including IEC 61850, DNP3, and Modbus.
Local control and monitoring: Local control and monitoring via large graphical display and buttons.
Flexible configuration options: The REF615-D is highly configurable to meet the specific needs of a variety of applications. It offers a variety of standard configuration options, as well as the ability to customize using application-specific Settings.
Application of REF615-D
The REF615-D is ideal for a wide range of applications in utility and industrial power distribution systems. Includes:
Protection of overhead lines and cable feeders: The REF615-D can be used to protect radial overhead lines and cable feeders, ring and mesh distribution networks. Overhead lines and cable feeders.
Substation and switchgear control: The REF615-D can be used to control substations and switchgear, including feeder switching, load shedding, and islands.
Power system Health Monitoring: The REF615-D can be used to monitor the health of the power system, including voltage, current and power factor.
Data collection and analysis: The REF615-D can be used to collect and analyze data for system optimization and fault location.
Advantages of using REF615-D
The REF615-D offers users several advantages, including:
Improved reliability: The REF615-D has a full range of protection and control features to help improve the reliability of the power system.
Improve efficiency: The REF615-D's advanced automation features help improve the efficiency of the power system.
Reduce maintenance costs: The REF615-D's self-diagnostic capabilities help reduce maintenance costs.
Extended System life: The REF615-D's rugged design helps extend the life of the power system.
Overall, the REF615-D is a powerful, reliable and versatile feeder protection and control relay ideal for a wide range of applications in utility and industrial distribution systems.

REF615-D 馈线保护和测控装置
