DS200DCFBG1BNC 电源板 提供稳定的直流电源

DS200DCFBG1BNC 电源板 提供稳定的直流电源

主要特点：
提供控制级电源：该DS200DCFBG1BNC为直流驱动器或励磁器提供控制级电源，确保为控制电路提供稳定可靠的电源。
电源 115 V AC：该板还提供 115 V AC 电压，通常用于为机柜冷却风扇供电，确保控制系统正常冷却。
包括各种电路：该DS200DCFBG1BNC包含多个关键电路，包括：
控制级电源：这些电源为控制电路提供稳定、准确的电压（+5、±15 和 ±24 V DC）。
电动机或发电机现场电源电路：这些电路管理电机或发电机场的电力输送，确保驱动系统的正常运行。
驱动电路：这些电路控制电枢 SCR 的栅极脉冲，调节电机的速度或扭矩。
监控电路：该板包括用于监控各种交流和直流信号的电路，例如电枢电流和电压、现场电流、交流线路电流和交流线路电压，为系统操作和诊断提供有价值的数据。
应用：
DS200DCFBG1BNC电源板专门设计用于风力、蒸汽和燃气轮机驱动的 Speedtronic Mark V 控制系统。它在为这些系统提供稳定的电源和监控功能方面发挥着至关重要的作用。
技术规格：
输入电压范围：38 至 115 VAC
控制级电源输出：
+5 伏直流电
±15 伏直流电
±24 伏直流电
115 V AC 输出
监控电路：
电枢电流和电压
现场电流
交流线路电流
交流线路电压幅度和相序
工作温度：-20°C 至 +60°C
防护等级：IP67防护等级

DS200DCFBG1BNC 电源板 提供稳定的直流电源

Main features:
Providing control level power: The DS200DCFBG1BNC provides control level power to the DC driver or exciter, ensuring a stable and reliable power supply to the control circuit.
Power supply 115 V AC: The board also provides 115 V AC voltage, which is typically used to power cabinet cooling fans and ensure proper cooling of the control system.
Includes various circuits: The DS200DCFBG1BNC contains a number of key circuits, including:
Control-level power supplies: These supplies provide stable, accurate voltages (+5, ±15, and ±24 V DC) to the control circuit.
Electric motor or generator field power circuits: These circuits manage the delivery of power to the motor or generating airport and ensure the proper operation of the drive system.
Drive circuits: These circuits control the gate pulse of the armature SCR and regulate the speed or torque of the motor.
Monitoring circuits: The board includes circuits for monitoring various AC and DC signals, such as armature current and voltage, field current, AC line current, and AC line voltage, providing valuable data for system operation and diagnostics.
Applications:
The DS200DCFBG1BNC power supply board is specially designed for Speedtronic Mark V control systems for wind, steam and gas turbine drives. It plays a vital role in providing stable power and monitoring functions for these systems.
Technical specifications:
Input voltage range: 38 to 115 VAC
Control level power output:
+5 volts DC
±15 volts DC
±24 volts DC
115 V AC output
Monitoring circuit:
Armature current and voltage
Field current
Ac line current
Ac line voltage amplitude and phase sequence
Operating temperature: -20°C to +60°C
Protection level: IP67 protection level
