JETNET3008F-S 以太网光纤交换机

JETNET3008F-S 以太网光纤交换机

JETNET3008F-S 是一款专为工业应用而设计的 8 端口快速以太网光纤交换机。 它提供 6 个 RJ-45 快速以太网铜缆端口和 2 个快速以太网光纤端口，支持多模和单模光纤。 该开关采用坚固的 IP31 级铝制外壳，可在 -10°C 至 +70°C 的宽温度范围内工作。 它还具有冗余电源，可提高可靠性。
主要特点
6 个 RJ-45 快速以太网铜缆端口
2 个快速以太网光纤端口（多模或单模）
支持自动协商和自动 MDI/MDIX
存储转发交换架构
冗余电源
DIN导轨安装
IP31 级铝制外壳
工作温度：-10°C 至 +70°C
应用
JETNET3008F-S 非常适合各种工业自动化应用，包括：
机器控制：该开关可用于将工业机器和设备连接到网络。
过程控制：JETNET3008F-S 可用于将过程控制设备连接到网络。
数据采集：交换机可用于从传感器和其他设备收集数据并将其发送到中央控制器。
楼宇自动化：JETNET3008F-S 可用于将楼宇自动化系统连接到网络。
规格
下表总结了 JETNET3008F-S 的主要规格：
规范价值
端口类型 6 个 RJ-45 快速以太网铜缆，2 个快速以太网光纤（多模或单模）
端口速度 10/100 Mbps
开关容量 2 Gbps
背板带宽 2 Gbps
自动协商 是的
自动 MDI/MDIX 是的
交换架构 存储和转发
电源 24VDC冗余
功耗 10瓦
工作温度 -10°C 至 +70°C
湿度 0% 至 95% RH（非冷凝）
安装 DIN导轨安装
尺寸 120 x 85 x 30 毫米（4.72 x 3.35 x 1.18 英寸）
重量 300 克 （10.58 盎司）

JETNET3008F-S 以太网光纤交换机

JETNET3008F-S is an 8-port fast Ethernet Fibre Channel switch designed for industrial applications. It offers six RJ-45 fast Ethernet copper ports and two fast Ethernet fiber ports, supporting both multi-mode and single-mode fiber. The switch features a robust IP31 grade aluminum housing that operates over a wide temperature range from -10°C to +70°C. It also has a redundant power supply for increased reliability.
Main feature
Six RJ-45 fast Ethernet copper ports
2 Fast Ethernet fiber ports (multi-mode or single-mode)
Supports automatic negotiation and automatic MDI/MDIX
Store-and-forward switching architecture
Redundant power supply
DIN rail mounting
IP31 grade aluminum housing
Operating temperature: -10°C to +70°C
Apply
The JETNET3008F-S is ideal for a variety of industrial automation applications, including:
Machine control: This switch can be used to connect industrial machines and equipment to the network.
Process control: JETNET3008F-S can be used to connect process control devices to the network.
Data acquisition: Switches can be used to collect data from sensors and other devices and send it to a central controller.
Building Automation: JETNET3008F-S can be used to connect building automation systems to the network.
specification
The following table summarizes the main specifications of the JETNET3008F-S:
Normative value
Port Type 6 RJ-45 Fast Ethernet copper cables, 2 Fast Ethernet optical fibers (multi-mode or single-mode)
Port speed 10/100 Mbps
Switching capacity 2 Gbps
The backplane bandwidth is 2 Gbps
Automatic negotiation. Yes.
Automatic MDI/MDIX Yes
Switch architecture store and forward
The power supply is 24VDC redundant
Power consumption 10 watts
Operating temperature -10°C to +70°C
Humidity 0% to 95% RH (non-condensing)
Install DIN rail mounting
Dimensions 120 x 85 x 30 mm (4.72 x 3.35 x 1.18 in)
Weight 300g (10.58 oz)
