UTNH系列光共享集线器单元(在本手册中称为光共享集线器单元)用于信息和控制网络TC-net 100构成TC-net 100光传输线。它采用具有8个端口的MT-RJ光纤连接器。

集线器单元还有一个用于RJ-45模块化连接器的端口，该端口可以连接到TC-net 100 (双绞线)设备。使用单个单元时,将光共享集线器单元用于线路A传输线UTNH23A

(为TC-net 100安装SNMP)或用于线路B传输线UTNH23B的光共享集线器单元。外部视图和系统配置示例如下所示。

●UTNH23A:用于A线传输线的主光共享集线器单元(已安装SNMP)

●UTNH23B:用于B线传输线的主光共享集线器单元

UTNH23A TOSHIBA 数字信号处理器(DSP)专门用于信号处理

The UTNH Series Optical Shared Hub Unit (referred to in this manual as the Optical Shared Hub Unit) is used for the information and control network TC-net 100 to form the TC-net 100 optical transmission line. It uses an MT-RJ fiber optic connector with 8 ports.

The hub unit also has a port for the RJ-45 modular connector, which can be connected to TC-net 100 (twisted pair) devices. When using A single unit, the optical shared hub unit is used for the line A transmission line UTNH23A

(Install SNMP for TC-net 100) or optical shared hub unit for Line B transmission line UTNH23B. Examples of external views and system configurations are shown below.

UTNH23A: Master optical shared hub unit for A-line transmission lines (SNMP installed)

UTNH23B: Main optical shared hub unit for B-line transmission lines
