LWN2660-6EG 交流/DC DIN导轨SUP

LWN2660-6EG 交流/DC DIN导轨SUP

BEL POWER SOLUTIONS INC w 系列开关模式电源是双输出主控交流 – 直流或直流 – 直流回扫转换器，开关频率恒定为 130kHz 。其高效率是由于输入电压的功率因数校正单步转换为低输出电压。输入电压范围为 85VAC 至 264VAC 至 90VDC 至 350Vdc 。此电源在 24VDC 输出电压下具有 5A 的额定输出电流。其输出电压可在 24VDC 至 25.8vdc 的范围内调节、并提供电气隔离安全超低电压（ selv ）和低输出噪声。
注意：
工作温度未降低额定值

特点和优势
绿色 led 、用于指示状态
效率高达 87%
高度可靠
独立调节输出
内部保护电路
平均故障间隔时间大于 60 万小时
工作温度范围 -40°c 至 60°c
额定功率高达 250W
坚固的 35mm 卡入式设计
几乎无起动电流

LWN2660-6EG 交流/DC DIN导轨SUP

BEL POWER SOLUTIONS INC w Series switching mode power supplies are dual output master AC-DC or DC-DC flyback converters with a constant switching frequency of 130kHz. Its high efficiency is due to the single step conversion of the input voltage to the low output voltage by power factor correction. Input voltage ranges from 85VAC to 264VAC to 90VDC to 350Vdc. This power supply has a rated output current of 5A at 24VDC output voltage. Its output voltage can be adjusted in the range of 24VDC to 25.8vdc, and provides electrically isolated safe Ultra-low voltage (selv) and low output noise.
Attention:
Operating temperature does not decrease the rating

Characteristics and advantages
Green led, for status indication
Efficiency up to 87%
Highly reliable
Independent control output
Internal protection circuit
The average time between failures is greater than 600,000 hours
Operating temperature range -40°c to 60°c
Rated power up to 250W
Rugged 35mm snap-in design
Almost no starting current
