MVI69-PDPMV1是一个Prosoft技术模块，用作Profibus主网络模块。该模块特别适用于Profibus分散外围设备(DP)版本1工业网络。它是一个单槽模块，直接安装在1769底板上，供1769 CompactLogix控制器使用。此外，该模块还与MicroLogix 1500 LRP控制器兼容。

MVI69-PDPMV1支持多达125个从设备的通信，带或不带ProfiBus中继器。它能够处理多达1536个循环字节的输入和1536个字节的输出数据。此外，该模块支持被配置为提供扩展的诊断数据。

MVI69-PDPMV1配有一(1)个9针Sub-D母连接器，带有就绪、运行、错误和令牌LED指示灯。该端口支持高达12 Mbps的标准Profibus传输。多个Profibus主机可以安装在一个插槽中；因此，允许主机控制器与各种ProfiBus分段通信。

MVI69-PDPMV1可以使用RSLogix 5000编程软件进行配置。此外，制造商提供的附件工具可用于帮助简化硬件配置和定义该模块的数据传输。它可以与ProSoft配置生成器以及ProfiBus comDTM软件一起使用。

MVI69-PDPMV1 DPV1 主站模块 通信接口模块
MVI69-PDPMV1 is a Prosoft technology module used as the main Profibus network module. The module is particularly suitable for Profibus Distributed Peripherals (DP) version 1 industrial networks. It is a single slot module that is mounted directly on the 1769 baseplate for use by the 1769 CompactLogix controller. In addition, the module is compatible with the MicroLogix 1500 LRP controller.

The MVI69-PDPMV1 supports communication of up to 125 slave devices, with or without ProfiBus Repeaters. It is capable of processing up to 1536 bytes of input and 1536 bytes of output data. In addition, the module supports being configured to provide extended diagnostic data.

The MVI69-PDPMV1 is equipped with one (1) 9-pin Sub-D female connector with Ready, Run, error, and token LED indicators. The port supports standard Profibus transfers of up to 12 Mbps. Multiple Profibus hosts can be installed in a single slot; Therefore, the host controller is allowed to communicate with various ProfiBus segments.

The MVI69-PDPMV1 can be configured using the RSLogix 5000 programming software. In addition, accessory tools provided by the manufacturer can be used to help simplify hardware configuration and define data transfer for this module. It can be used with ProSoft configuration Generator as well as ProfiBus comDTM software.
